Non-Insulating Aluminum Alloy Sliding Door

Core advantage

1. The Non-Insulating Aluminum Alloy Sliding Doors supplied by Guanye Door and Window Factory have an extremely high cost-performance ratio. They do not have insulation strips or complex bridging processes, and the profiles and processing costs are low. The price is only 60%-80% of the insulated sliding doors. They are suitable for projects with limited budgets and no need for energy conservation and insulation.

2. The structure is simple and the installation is convenient. The one-piece formed aluminum profiles have no multi-cavity or insulation strip joints. The corner assembly and installation are more efficient, with a short construction period and low labor costs.

3. The space utilization is high. The doors can be opened and closed horizontally without requiring a 90° rotation space. They do not occupy indoor or outdoor passages and are suitable for small户型， narrow spaces， and wide door openings.

4. The view is transparent and the appearance is flexible. They can be made with extremely narrow frames (such as 24.6mm) and large glass designs. They have good lighting and a wide visual field. They support multi-color painting and are suitable for modern， minimalist， and industrial-style decorations.

5. Maintenance is simple and the durability is strong. There is no aging problem of insulation strips. They are resistant to wind， pressure， and corrosion. The rollers and tracks are easy to clean and replace， and the service life is long.

6. The opening and closing is smooth and the noise is controllable. They are equipped with rubber-sealed bearings and stainless steel tracks. The sliding and pushing are light and smooth with low noise. They can also be selected with a recessed drainage and frame-encased door structure to enhance water tightness and wind resistance.

Core technical specifications of Guanyi non-insulated sliding door

1. Profile specifications

- Material: Non-Insulating Aluminum Alloy Sliding Door uses 6063-T5 aluminum alloy, with a wall thickness of 2.0mm, and can reach 2.5-3.0mm for heavy-duty.

- Structure: Integrated molding, no insulation strip, frame enclosing the door / door enclosing the frame design, corner sealing reinforcement.

- Track: Double track / triple track, flat track / high-low track / barrier track, stainless steel / aluminum alloy material, with drainage holes.

2. Glass configuration.

- Insulated glass: 5+9A+5 / 5+12A+5, basic sound insulation (about 25 decibels), no insulation effect.

- Optional: frosted, long rainbow, laminated, Low-E (only shading, no insulation).

3. Hardware and sealing

- Pulleys: Rubber-coated bearing wheels, load-bearing 80-150kg per door, adjustable height 0-4mm.

- Locks: Single-point / multi-point locks, anti-slip handles, locking seat for clamping plates, convenient installation.

- Sealing: 2-4 strips / felt strips, cross-sealing, water tightness ≥ 3 levels, air tightness ≥ 4 levels (standard).

4. Performance parameters

- Heat insulation: K value ≥ 5.0W/(m²·K), no break bridge, fast heat conduction.

- Wind resistance: 6-8 levels (standard), heavy-duty up to 10 levels.

- Sound insulation: 20-28 decibels (single layer), 25-32 decibels (insulated).

- Opening and closing times: ≥ 50,000 times, with proper maintenance, it can reach 80,000 times.

Application fields

1. Residential scenarios

- Interior partitions: kitchen, study, balcony, cloakroom, living room division, no space occupation, good lighting.

- Balcony doors: non-energy-saving residences, washing and drying balconies, convenient ventilation, high cost-effectiveness.

- Bathroom doors: frosted glass, waterproof and moisture-proof, easy to clean.

2. Commercial and public scenarios

- Shops/Stores: display doors for windows, strong display effect, easy opening and closing.

- Office partitions: open or semi-open spaces, flexible partitioning, transparent and beautiful.

- Industry/warehouse: factory side doors, logistics channels, wide width suitable, wind-resistant and durable.

- Temporary buildings/Simple houses: projects with limited budget, no need for insulation.

Applicable and Inapplicable Scenarios

- Suitable: Non-Insulating Aluminum Alloy Sliding Door is suitable for those with limited budgets, who do not need energy conservation and insulation, and who prioritize cost-effectiveness and transparency; interior partitions, non-energy-saving balconies, shops, industrial passageways.

- Not Suitable: Cold and hot regions, energy-efficient residences, high sound insulation requirements (such as street-facing bedrooms), high-end energy-efficient buildings.

Summary

Guanye Doors' non-insulated sliding doors have core advantages such as simple structure, high cost-effectiveness, space friendliness, and ease of maintenance. They are the mainstream choice for basic sliding doors. Although they sacrifice the insulation and heat preservation performance, they have significant advantages in terms of lighting, space, and cost, precisely meeting the needs of non-energy-saving scenarios. They are widely used in home decoration, commercial, and industrial fields.
